Mill TC / Test Certificate Support
Product Range
Sheet, Plate & Coil
Flat products supplied in commercial, boiler, pressure vessel, structural and corrosion-resistant grades.
Ready StockCustom SizesThird Party InspectionExport Packing
Category: Ferrous & Non-Ferrous Metals
Sheet, Plate & Coil Specifications
Every order is checked for grade, dimension, surface condition and packing before dispatch. Supply can be arranged in standard lengths, cut lengths or fabrication-ready bundles.
| Forms | Sheet, plate, coil, strip, shim, chequered plate and cut-to-size blanks |
|---|---|
| Standards | ASTM A240, A36, A516, A387, IS, DIN, EN, JIS |
| Size Range | Thickness 0.3 mm to 150 mm, standard and project sizes |
| Materials | Stainless steel, carbon steel, boiler quality, alloy steel, duplex, super duplex and nickel alloys |
| Applications | Fabrication, tanks, pressure vessels, heat exchangers, platforms, ducts and process equipment |
Value Added Services
- Cutting, beveling, threading or machining as applicable
- PMI, hardness, hydro, ultrasonic and dimensional inspection
- Material test certificates and third-party inspection coordination
- Domestic and export-safe packing with clear product marking
Available Materials
- SS 304 / 304L / 316 / 316L / 321 / 310 / 904L
- IS 2062 / ASTM A36 structural grades
- Boiler quality ASTM A516 Gr. 60 / 70
- Alloy steel ASTM A387 Gr. 11 / 22 / 91
- Duplex, Super Duplex, Inconel, Monel and Hastelloy
Selection Notes
Use stainless steel for corrosion resistance, carbon steel for general process piping, alloy steel for elevated temperature service, duplex grades for chloride environments and nickel alloys for severe chemical duties.
Ask For Grade Guidance| Stainless Steel | ASTM A240 304/304L/316/316L/316Ti/309/310/317/317L/321/347/409/410/430/904L/SMO 254 / AL6XN |
|---|---|
| Duplex & Super Duplex | Standard: UNS S31803/S32205 (2205) Lean: UNS S32304 (2304) Super Duplex: UNS S32750 (2507), UNS S32760 (Zeron 100) |
| Alloy Steel Pipe | ASTM A387 Gr. 11, 12, 22, 5, 91 (CL 1/2) |
|---|---|
| Carbon Steel | ASTM A 36, S275 JR, IS 2062 Gr. A/B |
| Aluminium | ASTM B 928, 5083(A95083), 5086(A95086), 5052(A95052), T6061(A96061) |
|---|---|
| Spring Steel Coils | CR C55, C80, C62, C45 |
| Cupro Nickel | ASTM B171 C70600 (90:10), C71500 (70:30) |
| Monel Standard | ASTM B127 N04400, DIN N05500 |
|---|---|
| Sheets | 0.8mm to 4mm thk, 1000 to 2000mm Width, 2000 to 6000mm Length |
| Plates | 5mm to 100mm thk, 1000 to 2000mm Width, 2000 to 8000mm Length |
| Coils | 0.1mm to 12mm thk, 10mm to 1500mm Width |
| Foils | 0.01mm to 0.3mm thk, in any width |
| Strips | 1mm to 100mm thk, 10mm to 900mm Width, 1000 to 6000mm Length |
| Nickel | ASTM B162 N02200, N02201 |
|---|---|
| Inconel/Incoloy | ASTM B 168 (N06600, N06601), ASTM B 409 (N08800, N08810) |
| Hastelloy | ASTM B 575 N10276, N06022, B 333 N10665 |
| Titanium | ASTM B 265 Gr.1/2/3/4/7/11 (Pure), Gr.5/23 (Alloys) |
Sheet, Plate, Coil Dimensions Chart
| Product | Thickness (mm) | Standard Size 1 | Standard Size 2 | Standard Size 3 | Finish / Note |
|---|---|---|---|---|---|
| Sheet | 0.3 - 6.0 | 1000 x 2000 | 1220 x 2440 | 1500 x 3000 | 2B / BA / No.4 / HL |
| Plate | 6.0 - 100 | 1250 x 2500 | 1500 x 3000 | 2000 x 6000 | HR / CR / polished |
| Coil | 0.3 - 6.0 | 1000 | 1220 | 1500 | Slit / full width |
| Shim | 0.05 - 0.3 | 100 x 1000 | 300 x 1000 | 600 x 1000 | Roll / strip |
| Strip | 0.1 - 3.0 | 10 - 600 width | As required | Coil form | Slit edge |
